OD114.3mm Nikel N02200 Nikel Alaşımlı Boru
Temel Özellikler
Menşe Yeri:
Çin
Marka Adı:
Torich
Sertifikasyon:
IS09001 ISO14001 TS16949
Model Numarası:
ASTM B163
Ticaret Mülkleri
Minimum Sipariş Miktarı:
0,5 ton
Fiyat:
pazarlık edilebilir
Ödeme Şartları:
L / C, T / T
Tedarik Yeteneği:
Yılda 60000 ton
Ürün Özetleri
Nikel N02200 Borular/Tüpler Hızlı bir detay: Aşırı doz:3.18-114.3 mm. WT:0.5-12 mm. UNS:N02200/W.Nr.2.4060 Nikel 200 Kimyasal bileşimi: Alaşım Ni+Co Fe C M Evet. Cu S Nikel 200 99 dakika. 0.4 en fazla 0.15 en fazla 0.35 En fazla 0.30 En fazla 0.25 En fazla 0.25 En fazla. Nikel 200 Fiziksel ...
Ürün Ayrıntıları
Vurgulamak:
Nikel N02200 nikel alaşımlı boru
,OD114.3mm Nikel Alaşımlı Boru
,OD114.3mm nikel 200 boru
Standard:
Nikel N02200
Material:
Nikel N02200
OD:
3.18-114.3 mm
WT:
0,5-12 mm
Ürün Tanımı
Nikel N02200 Borular/Tüpler
Hızlı bir detay:
Aşırı doz:3.18-114.3 mm.
WT:0.5-12 mm.
UNS:N02200/W.Nr.2.4060
Nikel 200 Kimyasal bileşimi:
| Alaşım | Ni+Co | Fe | C | M | Evet. | Cu | S | ||
| Nikel 200 | 99 dakika. | 0.4 en fazla | 0.15 en fazla | 0.35 En fazla | 0.30 En fazla | 0.25 En fazla | 0.25 En fazla. |
Nikel 200 Fiziksel özellikler
| yoğunluk | 8.89g/cm3 |
| Erime noktası | 1435-1466°C |
Nikel 200 Mekanik özellikler
| Alaşım | Çekim sıklığı ((Mpa)Rm N/m2 | Verim gücü ((Mpa)RP0.2N/mm2 | Uzunluk A5 % |
| Nikel 200 | 415-585 | 105-310 | 35-55 |
| GB | UNS | SEW VDIUV | BS | AFNOR | |
| Incoloy 800 | NS111 | N08800 | W.Nr.1.4876 X10NiCrAlTi3220 | NA15 | Z8NC32.21 |
| Incoloy 800H | NS112 | N08810 | W.Nr.1.4958 X5NiCrAlTi31-20 | NA15 ((H) | |
| Incoloy 800HT | N08811 | W.Nr.1.4959 X 8 NiCrAlTi32-21 | |||
| Incoloy 825 | NS142 | N08825 | W.Nr.2.4858 NiCr21Mo | NA16 | NC21FeDu |
| Inconel 600 | NS313 | N06600 | W.Nr.2.816 NiCrl5Fe | NA14 | NC15FE |
| Inconel 601 | N06601 | W.Nr.2.4851 NiCr23Fe | NC23FeA | ||
| Inconel 625 | NO6625 | W.Nr.2.4856 NiCr22Mo9Nb
| NA21 | NC22DNb |
