Özel Yapısal Alaşım Çelik Boru 38CrMoAl ISO 41CrAlMo74 GB / T3077
Temel Özellikler
Menşe Yeri:
Çin
Marka Adı:
Torich
Sertifikasyon:
ISO 9001:2008 , TS16949
Model Numarası:
Alaşım Çelik 38CrMoAl ISO 41CrAlMo74
Ticaret Mülkleri
Minimum Sipariş Miktarı:
5mt
Fiyat:
pazarlık edilebilir
Ödeme Şartları:
L/C, T/T
Tedarik Yeteneği:
6000MT/ay
Ürün Özetleri
Alaşımlı çelik boru sınıfı GB/T3077 38CrMoAl ISO 41CrAlMo74 Yapısal çelik borular standardı GB/T3077: 38CrMoAl ISO: 41CrAlMo74 GOST: 38X2MO.A(38XMO.A) DIN: 41CrAlMo7 34CrAlMo5 BS: 905M39 905M31 NF: 40CAD6.12 30CAD6.12 Kimyasal bileşim:C:0.35 ~ 0.42Si:0.20 ~ 0.45Mn:0.30 ~ 0.60S: ≤ 0.035P: ≤ 0.035Cr:1...
Ürün Ayrıntıları
Vurgulamak:
Alaşımlı çelik boru
,dikişsiz alaşımlı çelik boru
Product Name::
Alaşımlı çelik boru
Grade::
GB/T3077, 38CrMoAl, ISO41CrAlMo74
Material:
alaşım çelik
Production:
Sıcak Biten ve Biten Soğuk
Ürün Tanımı
Alaşımlı çelik boru sınıfı GB/T3077 38CrMoAl ISO 41CrAlMo74 Yapısal çelik borular standardı
GB/T3077: 38CrMoAl
ISO: 41CrAlMo74
GOST: 38X2MO.A(38XMO.A)
DIN: 41CrAlMo7 34CrAlMo5
BS: 905M39 905M31
NF: 40CAD6.12 30CAD6.12
Kimyasal bileşim:
C:0.35 ~ 0.42
Si:0.20 ~ 0.45
Mn:0.30 ~ 0.60
S: ≤ 0.035
P: ≤ 0.035
Cr:1.35 ~ 1.65
Ni: ≤ 0.030
Cu: ≤ 0.030
Mo:0.15 ~ 0.25
Çekim gücü:σb (MPa):≥980(100)
Verim gücü:σs (MPa):≥835(85)
Uzunluk:δ5 (%):≥14
ψ (%): ≥50
Etkisi:Akv (J):≥71
αkv (J/cm2):≥88(9)
ISO: 41CrAlMo74
GOST: 38X2MO.A(38XMO.A)
DIN: 41CrAlMo7 34CrAlMo5
BS: 905M39 905M31
NF: 40CAD6.12 30CAD6.12
Kimyasal bileşim:
C:0.35 ~ 0.42
Si:0.20 ~ 0.45
Mn:0.30 ~ 0.60
S: ≤ 0.035
P: ≤ 0.035
Cr:1.35 ~ 1.65
Ni: ≤ 0.030
Cu: ≤ 0.030
Mo:0.15 ~ 0.25
Çekim gücü:σb (MPa):≥980(100)
Verim gücü:σs (MPa):≥835(85)
Uzunluk:δ5 (%):≥14
ψ (%): ≥50
Etkisi:Akv (J):≥71
αkv (J/cm2):≥88(9)
Sertlik≤ 229HB:30mm
