16MnCr6 20MnCr5 20CrMn Alaşımlı Çelik Boru, Soğuk Çekilmiş Dikişsiz Çelik Boru TS16949
Temel Özellikler
Menşe Yeri:
Çin
Marka Adı:
Torich
Sertifikasyon:
ISO 9001:2008 , TS16949
Model Numarası:
20MnCr5, 20CrMn
Ticaret Mülkleri
Minimum Sipariş Miktarı:
5mt
Fiyat:
pazarlık edilebilir
Ödeme Şartları:
L/C, T/T
Tedarik Yeteneği:
6000MT/ay
Ürün Özetleri
Alloy çelik borular ve borular 16MnCr5 20MnCr5 20CrMn Alaşımlı çelik sınıfı20MnCr5eşdeğer20CrMn Alaşımlı çelik sınıfı çelik borular20MnCr5: 16MnCr5C:0.14-0.19,Mn:1.00-1.30,P≤0.035,S≤0,010-0.050,Cr:0.80-1.10,Si ≤ 0.40 20MnCr5C:0.17-0.22,Mn:1.10-1.50,P≤0.035,S≤0,10-0.050,Cr:1.00-1.30,Si ≤ 0.25 20CrMnC...
Ürün Ayrıntıları
Vurgulamak:
alaşımlı çelik dikişsiz boru
,dikişsiz alaşımlı çelik boru
Material:
alaşım çelik
Grade:
20MnCr5 20CrMn
Production:
Soğuk çekilmiş veya sıcak bitiş
Type:
Kesintisiz
Ürün Tanımı
Alloy çelik borular ve borular 16MnCr5 20MnCr5 20CrMn
Alaşımlı çelik sınıfı20MnCr5eşdeğer20CrMn
Alaşımlı çelik sınıfı çelik borular20MnCr5:
16MnCr5
C:0.14-0.19,
Mn:1.00-1.30,
P≤0.035,
S≤0,010-0.050,
Cr:0.80-1.10,
Si ≤ 0.40
20MnCr5
C:0.17-0.22,
Mn:1.10-1.50,
P≤0.035,
S≤0,10-0.050,
Cr:1.00-1.30,
Si ≤ 0.25
20CrMn
C:0.17-0.23,
Mn: 0.90-1.20,
Cr:1.00-1.30,
Si:0.17-0.37
Mekanik özellikleri:
Çekim gücü:Min 885Mpa
Üretim gücü: min 685Mpa
Uzunluk:Min 12%
Sertlik: en fazla 190HB
C:0.14-0.19,
Mn:1.00-1.30,
P≤0.035,
S≤0,010-0.050,
Cr:0.80-1.10,
Si ≤ 0.40
20MnCr5
C:0.17-0.22,
Mn:1.10-1.50,
P≤0.035,
S≤0,10-0.050,
Cr:1.00-1.30,
Si ≤ 0.25
20CrMn
C:0.17-0.23,
Mn: 0.90-1.20,
Cr:1.00-1.30,
Si:0.17-0.37
Mekanik özellikleri:
Çekim gücü:Min 885Mpa
Üretim gücü: min 685Mpa
Uzunluk:Min 12%
Sertlik: en fazla 190HB
Kesin çelik borular16MnCr5 20MnCr5Konteyner yükleme:
