Kondenser Düz Bakır Nikel Tüpler Gr CuNi90 10 C70600 ASTM B111 Standardı
Temel Özellikler
Menşe Yeri:
Çin
Marka Adı:
Torich
Sertifikasyon:
ISO9001
Model Numarası:
ASTM B111
Ticaret Mülkleri
Minimum Sipariş Miktarı:
500KGS
Fiyat:
pazarlık edilebilir
Ödeme Şartları:
T / T, L / C
Tedarik Yeteneği:
Bir yıl 5000 ton
Ürün Özetleri
ASTM B111 /EN 12451 Düz bakır nikel borular Sınıf:C68700 C44300 C70600 C71500 C26000 C27000 C27200. Uygulama: kondansör, kanatlı borular, gemi onarımı ve inşaat, okyanus mühendisliği TUV PED, CCS ve Lloyd's ISO 9001 tarafından onaylanmıştır. Genel boyut: Müşterinin gereksinimlerine göre OD 3-50mm WT ...
Ürün Ayrıntıları
Vurgulamak:
Alaşımlı çelik boru
,dikişsiz alaşımlı çelik boru
Material:
CuNi90 10 C70600
Shape:
Düz
Standard:
ASTM B111
Ürün Tanımı
ASTM B111 /EN 12451 Düz bakır nikel borular
Sınıf:C68700 C44300 C70600 C71500 C26000 C27000 C27200.
Uygulama: kondansör, kanatlı borular, gemi onarımı ve inşaat, okyanus mühendisliği
TUV PED, CCS ve Lloyd's ISO 9001 tarafından onaylanmıştır.
Genel boyut: Müşterinin gereksinimlerine göre OD 3-50mm WT 0.8-20mm.
| Kimyasal Gereksinimler | |||||||||||||
| Bakır veya bakır alaşımı UNS No. | Bakır | Teneke | Al | Ni İkl. | Pb max | Fe max | Zn max | En fazla | - Evet. | Sb | Pmax | Kr | Diğer isimli elementler |
| C44300 | 70.0-73.0 | 0.9-1.2 | 0.07 | 0.06 | Geri kalan | 0.02-0.06 | |||||||
| C44400 | 70.0-73.0 | 0.9-1.2 | 0.07 | 0.06 | Geri kalan | 0.02-0.10 | |||||||
| C44500 | 70.0-73.0 | 0.9-1.2 | 0.07 | 0.06 | Geri kalan | 0.02-0.10 | |||||||
| C60800 | Geri kalan | 5.0-6.5 | 0.1 | 0.1 | 0.02-0.35 | ||||||||
| C61300 | Geri kalan | 0.20- 0.50 | 6.0-7.5 | 0.15 en fazla | 0.01 | 2.0-3.0 | 0.1 | 0.2 | 0.015 | ||||
| C61400 | Geri kalan | 6.0-8.0 | 0.01 | 1.5-3.5 | 0.2 | 1.0 | 0.015 | ||||||
| C68700 | 76.0-79.0 | 1.8-2.5 | 0.07 | 0.06 | Geri kalan | 0.02-0.06 | |||||||
| C70400 | Geri kalan | 4.8-6.2 | 0.05 | 1.3-1.7 | 1.0 | 0.30-0.80 | |||||||
| C70600 | Geri kalan | 9.0-11.0 | 0.05 | 1.0-1.8 | 1.0 | 1.0 | |||||||
| C70620 | 86.5 dakika | 9.0-11.0 | 0.02 | 1.0-1.8 | 0.5 | 1.0 | 0.02 | C.05max S.02max | |||||
| C71000 | Geri kalan | 19.0-23.0 | 0.05 | 0.50-1.0 | 1.0 | 1.0 | |||||||
| C71500 | Geri kalan | 29.0-33.0 | 0.05 | 0.4-1.0 | 1.0 | 1.0 | |||||||
| C71520 | 65.0 dakika | 29.0-33.0 | 0.02 | 0.4-1.0 | 0.5 | 1.0 | 0.02 | C.05max S.02max | |||||
| C71640 | Geri kalan | 29.0-32.0 | 0.05 | 1.7-2.3 | 1.0 | 1.5-2.5 | C.06max S.03max | ||||||
| C72200 | Geri kalan | 15.0-18.0 | 0.05 | 0.50-1.0 | 1.0 | 1.0 | 0.30-0.70 | Si.03max Ti.03max | |||||
